METART-WW03B-Antique Copper Elevator Architectural Mesh

Specification

Material: SS201/ SS304 / SS316 and other alloy

Type: Rigid Architectural Mesh

Opening Area: 0%

Weight: Approx 10.7kg/ Square Meter

Finish: Antique Copper Plated

Screen Size: 2000mm x 4000mm ( for mill finish only)

GET A QUOTE

Introduction

As a popular elevator architectural mesh, METART-WW03B is the opposite side of our architectural wire mesh pattern, METART-WW03.

With the exact same specifications as METART-WW03, WW03B is a combination of 3x1.2mm stainless steel wire strips and 1.5mm straightened stainless steel wire rods.

After a super tight weaving process, this solid metal screen has no opening at all in both directions. There is still ventilation in between the crimped wires and rods, but it is almost 100% opaque.

This side of the mesh pattern looks and feels more flat and smooth and would be a good option for elevator cab interior cladding wire mesh and other commercial building interior wall cladding choices.





Please refer to the following specifications:

Material

Stainless Steel 201, 304 or 316 is optional

Type

Rigid mesh

Flat SS Strip ( Width x Thickness)

3x1.2mm

Rod Diameter

1.5mm

Rod Pitch

9.35mm

Overall Thickness of the fabric

3.6mm

Opening Area

0%

Block out

100%

Privacy Rate

100%

Weight:

10.7kg/Square Meter

Finish

Antique copper plating

Customized specifications and mini-orders are accepted.

All optional finishes

Mill Finish ( Original stainless steel bright finish) ,
Antique bronze plating, Antique copper plating, Antique brass plate Vacuum Titanium Plated-Golden, Titanium Plated Black, Titanium Plated Rose Gold, Painted, PVDF Coated, Powder Coated.

Note:
All the measurements, including wire thickness, diameter, opening, and overall thickness, are nominal numbers. The actual specification might have a tiny bit of tolerance, according to fabrication.

Application

GET A QUOTE
