Introduction

Titanium wire mesh is made of superior titanium wires that are valued for their high strength, lightweight, and corrosion-resistant properties which make Titanium mesh widely used in a great variety of industries.
Commercially Pure (CP) Titanium Alloys Mesh are over 99% titanium. Titanium wire mesh always has a protective oxide coating that prevents electrolytic reactions with other metals. Therefore, using baskets that are made of titanium wire mesh can improve the process efficiency of anodizing aluminum components.
According to its appearance, Titanium wire mesh is divided into Bright Titanium wire mesh (white Titanium wire mesh) and Black Titanium wire mesh. Both of them are made from pure titanium wires. The difference is the surface of white Titanium mesh has no impurities which are suitable for anodizing experiments, catalyst carrier supports, pure chemical liquid filtration, and the filtration of other non-contaminated solutions. But the black Titanium mesh surface has a layer of brushed graphite emulsion which is suitable for seawater desalination titanium and chemical filtration. The coating on the surface can slow down the corrosion and prolong the service life.
There are two commonly used grades of Titanium wire mesh.
CP Titanium Grade 1 wire mesh is also known as TA1 wire mesh, UNS R50250 wire mesh, W.Nr. 3.7025 wire mesh
Grade 1 is the softest titanium with the highest ductility and corrosion resistance. It has excellent cold-forming characteristics, welding properties, and high-impact toughness. Grade 1 titanium wire mesh is often used for architectural, medical, marine, and chemical processing manufacturing.

Key features of Ta1 Wire Mesh

Strength: The strength of titanium is said to be twice as much as carbon, and it is equal to three times the strength of aluminum.

Lightweight: Titanium is 40% lighter than stainless steam or low carbon steel, but still, it is much stronger than them.

Corrosion resistance: Titanium is one of the best metals to use in saltwater or seawater. As it is best suited for such conditions and experiences close to no corrosion.

No oxidization: As it does not get eroded so easily, the outer layer stays in pristine condition all the time. Hence, it eliminates the hassle of its maintenance.

EQUIVALENT STANDARDS
INDUSTEEL TRADEMARKS	UNS	EURONORMS EN	SUS
	UNS R50250	3.7025	…

Chemical Composition of TA1 Titanium wire mesh

Fe	C	N	H	O	Other	Ti
0.2 Max	0.08 Max	0.03 Max	0.015 Max	0.18 Max	0.5 Max	Balanced

Physical Properties of TA1 Titanium wire mesh

Property
Melting Range	1670°C (3040°F)
Density	4.51(G/CM3
Coefficient of Thermal Expansion	5.4(70-212 oF) / 9.7(20-100 oC)
Themal Conductivity	12.6(Btu.in/ft2.h. oF) / 21.7(W/m.oC)
Thermal Capacity (Specific Heat)	0.125(Btu/Ib.oF) / 520(J/Kg.oC)

Specification List:

Mesh Count /Inch	Wire Diameter		Aperture		Open Area %	Weight (LB) /100 Square Foot
Mesh Count /Inch	Inch	MM	Inch	MM	Open Area %	Weight (LB) /100 Square Foot
1 × 1	.080	2.03	.920	23.37	84.6	41.1
2 × 2	.063	1.60	.437	11.10	76.4	51.2
3 × 3	.054	1.37	.279	7.09	70.1	56.7
4 × 4	.063	1.60	.187	4.75	56.0	104.8
4 × 4	.047	1.19	.203	5.16	65.9	57.6
5 × 5	.041	1.04	.159	4.04	63.2	54.9
6 × 6	.035	.89	.132	3.35	62.7	48.1
8 × 8	.028	.71	.097	2.46	60.2	41.1
10 × 10	.025	.64	.075	1.91	56.3	41.2
10 × 10	.020	.51	.080	2.03	64.0	26.1
12 × 12	.023	.584	.060	1.52	51.8	42.2
12 × 12	.020	.508	.063	1.60	57.2	31.6
14 × 14	.023	.584	.048	1.22	45.2	49.8
14 × 14	.020	.508	.051	1.30	51.0	37.2
16 × 16	.018	.457	.0445	1.13	50.7	34.5
18 × 18	.017	.432	.0386	.98	48.3	34.8
20 × 20	.020	.508	.0300	.76	36.0	55.2
20 × 20	.016	.406	.0340	.86	46.2	34.4
24 × 24	.014	.356	.0277	.70	44.2	31.8
30 × 30	.013	.330	.0203	.52	37.1	34.8
30 × 30	.012	.305	.0213	.54	40.8	29.4
30 × 30	.009	.229	.0243	.62	53.1	16.1
35 × 35	.011	.279	.0176	.45	37.9	29.0
40 × 40	.010	.254	.0150	.38	36.0	27.6
50 × 50	.009	.229	.0110	.28	30.3	28.4
50 × 50	.008	.203	.0120	.31	36.0	22.1
60 × 60	.0075	.191	.0092	.23	30.5	23.7
60 × 60	.007	.178	.0097	.25	33.9	20.4

Known widely in the engineering sector, Inconel wire mesh shows excellent strength, resistance to oxidation, corrosion and even extreme foehn winds. It is used for aerospace, marine, chemical processing and power generation industries, allowing for efficacy and reliability in the most ghastly conditions. This article focuses on issues, purposes, and pros of Inconel wire mesh, while also stating Metart Building Tech as one of the leading suppliers of the product.

Inconel is designed nickel-chromium based superalloy that best operates in extreme conditions. Compared to other materials, Inconel wire mesh provides superior capabilities it does not get stressed or corroded and oxidation becomes several times easier. It is a requisite for sectors that require great filtering, structural soundness and durability.

Inconel Wire Mesh's crucial attributes.

1. High Temperature Sustainability to Function

It is able to withstand greater than 1000 degree celcius without fainting making it ideal for industrial and high heat purposes.

2. Corrosion Resistance of the Greatest Level

Incredibly resistant to oxidation, acidic environments, and chemicals in seawater making it extremely favourable in marine and chemical arenas.

3. Greater Toughness and Sturdiness

Extracts from the surface microclimate have been presented as markers which help indicate the stresses and temperatures under which crystals interact.

4. Flexible Weaving Patterns

These patterns can be supplied in basic, twill or Dutch style weaves to suit particular industrial needs.

Applications of Inconel Wire Mesh In The Industry

1. Aerospace Industry

Jet engines, turbines, exhaust parts and heat shields must withstand tremendous thermal stresses, which make this material essential.

2. Chemical Processing

Used for filtering, supporting catalysts, and heat exchangers in strong corrosive environments.

3. Marine and Offshore Operations

It has excellent resistance to saltwater which is useful in oil rigs, desalination stations, and other underwater constructions.

4. Power Generation

High performance Inconel 625 is widely used in nuclear reactors and steam generators, where high operational temperatures are normal.

5. Automotive And Gas Turbines

Inconel parts can be used in manifolds turbocharger turbines and other highly stressed and heated mobile components.

Why Metart Building Tech is the Best For Inconel Wire Mesh?

Metart Building Tech is one of the best manufacturers of Inconel wire mesh of any type, for practically any industry. Their Inconel wire mesh products made with Nickel Alloy 600 (Inconel 600) Wire Mesh is specially manufactured with great care and accuracy which makes them stand out from the rest of the market.

Benefits of Metart Building Tech’s Inconel Wire Mesh

Metart Being the Industry Leader, the weave patterns on their Inconel wire mesh products do not suffer from loosening or wearing off due to the use of more advanced weaving machinery.

• Custom Fabrication - Different sizes of the mesh, wire diameters, and weaving styles are available as per the needs of the application.

• Strict Quality Assurance - Compliance with international standards ensures superior performance and reliability.

• Industry Expertise – Many years of experience delivering specialized solutions for critical industries.

Conclusion

Inconel wire mesh is ideal for industries that need materials that can withstand very high temperatures, heat, and pressure. For extreme industrial applications where durability, heat resistance, and corrosion protection are of utmost importance, this is the most dependable option.

Metart Building Tech, as a manufacturer, provides the industry with the best Inconel 600 wire mesh that goes beyond set standards.

Check out Metart Building Tech’s collection of nickel alloy 600 wire mesh and find the perfect solution for your industrial application.
