METART-WW26B-Solar Control Architectural Screen Metal Mesh

Specification

Material: Stainless Steel 304 / Stainless Steel 316 / SS201

Type: Rigid Architectural Wire Mesh

Opening Area: 46%

Weight: Approx 6kg/Square Meter

Finish: Mill Finish

Screen Width: 4 meters, Maximum, Mill Finish

Screen Length: 30M rolls, Mill Finish

GET A QUOTE

Introduction

METART WW26B is the opposite side of the mill-finished woven wire pattern WW26.

This side of this architectural metal mesh is a flat surface which is also suitable for wall decorative wire mesh panels.

Please refer to the following specifications.

Material	Stainless Steel 304 or 316, Aluminum Alloy optional
Type	Rigid Metal Mesh
Wire Strip	2.2x1.2mm
Wire Rod Diameter	1.5mm
Clear Hole Size	2x16mm
Strip Pitch	4.2mm
Rod Pitch	17.5mm
The total thickness of the fabric	3.1mm
Opening Area	46%
Block out	54%
Privacy Rate	54%
Weight	6kg/Square Meter
Finish	Mill Finish.
The way of cutting	Straight Cut
All optional ways of cut	Straight Cut Only
All optional Finish	Mill Finish ( Original stainless steel bright finish）, Antique Bronze plating, Antique Copper plating, Antique brass plate, vacuum titanium plated, Painted, PVDF Coated,
