METART-WW42-7528-Black Painted Decorative Glass Mesh made from stainless steel crimped wires

Specification

Material: Stainless Steel 304 / Stainless Steel 316 /SS201

Type: Rigid Decorative Wire Mesh

Opening Area: 73.9%

Weight: Approx 2.5kg/Square Meter

Finish: Black Painted

Screen Width: Customized. within 3M (10')

Screen Length: Customized. maxiumum within 4000MM (13 feet)

GET A QUOTE

Introduction

This is a black-painted version of METART WW42-75298, made of 2.9x1.2mm flat wires. This pattern is very light weighted. It is rigid but not strong enough to be railing panels or facade mesh but we can adjust the wire diameter and thickness to meet the requirements of your projects.

This specification is only suitable for laminated glass mesh. We can have it painted in customized colors.
Please refer to the following specifications.

Material

Stainless Steel 304,316 or 201, optional

Type

Rigid mesh

Flattened Wire Strip

2.9x1.2mm

Biggest Hole Size

28x28mm

Smallest Hole Size

7.5x7.5mm

Slot Hole Size

7.5x28mm

The total thickness of the fabric

2.6mm

Opening Area

73.9%

Block out

26.1%

Privacy Rate

26.1%

Weight

2.5kg/Square Meter

Finish

Black Painted.

The way of cutting

Straight Cut

All optional ways of cut

Straight Cut, Diamond Cut.

All optional Finish

Mill Finish ( Original stainless steel bright finish),
Antique Bronze plating, Antique Copper plating, Antique brass plate, vacuum titanium plated, Painted, PVDF Painted.

Customized specifications and Mini order accepted.

Note:

All the measurements including wire thickness, diameter, opening, and overall thickness are nominal numbers. The actual specification might have a tiny bit of tolerance according to fabrication
